金屬加工系列--側取式單工位CNC機械手

Metalworking series --Side to take single-CNC robot

 專為CNC加工中心，數控車床應用設計，具有廣泛的適配性與兼容性，可實現快速取、送料、全程週期最快可達3.5秒。

Designed for CNC machining centers,CMC lathes application design,with a wide range of adaptation and compatibility ,enabling fast take ,feeding ,full cycle speeds no more than 3.5seconds.

-各軸均採用全伺服驅動，確保了精准高速地運行。

-側掛或落地式安裝，最短工作行程，滿足高效、快速的運行週期。

-分體式結構設計，有效降低主臂負荷，運行速度更快、更穩。

-Each axis servo drives are used in full to ensure accurate high-speed operation.

-Side hung or floor-mounted,the shortest work schedule to meet the efficient and fast operating cycle.

-Split design,effectively reduce the main arm load and enhance the stability of equipment operation.

人機界面The Man-machine Interface 產品優勢Product advantages -人員培訓時間短，程式簡單易學，快速設定行程，時間，功能成型接口 -實時的故障檢測提示，完整的I/O顯示 -系統安全性可靠，誤操作時系統提醒。 -Training time is short and program is easy to learn,including movement,process,time setting and formed interface. -Real-time fault detection and prompt, integrated I/O display -The system is security and reliable, reminding when operation system made by mistake. -7.5寸液晶屏（觸摸+按鍵） -可實現圓弧插補，直線插補，節省取件時間 -可實現模內多點取件， -可實現當前程式存儲，節省調整時間 -多種語言（中，繁，英，日，韓，泰） -運作模式齊全，可推疊，排列，裝箱，自由置放，外部剪切 -單步運行功能，可單步步進調試 -可完全診斷文本錯誤資訊及時間記錄 -A7.5-inch LCD screen(touch and buttons) -It canrealize circular arc interpolation and linear interpolation,save pick-up time -It can realizemulti-point picking up in intramode -It can realize the current program storage,save the time of adjustment. -Support multiple languages (Chinese,Traditional Chinese character,English,Japanese,Korean,Thai) -it has completed operation pattern,can stackable,arrangement,packing,free placement,external shear -One-step operation function,can single step by step into the debugging. -It can completely diagnostic text errors and time recording   技術合作興品牌零部件   Technical cooperation with brand parts   威特爾對品質的追求在成本面前毫不妥協，產品核心零部件均採用國際高端品牌提供商，為產品的高品質和高性能提供了有力的保障。   VICTOR pursuit of quality costs in the face of uncompromising products are core components adopt international provider of high-end brands,high product quality and performance provided a strong guarantee.

公司簡介

Company Profile

    深圳威特爾自動化科技有限公司，國家高新技術企業，專注於工業裝備智能研發、製造與系統集成應用，以及智慧工廠整體解決方案。

    威特爾核心技術團隊，憑藉20年的國外先進的技術績澱，勇於探索創新，已掌握多項智能裝備領域具有自主知識產權的核心技術，自主研發生產的工業機器人、機械手已廣泛應用塑膠射出成型，CNC金屬加工，五金衝壓、自動噴塗、碼垛搬運、五金焊接等領域，尤其在薄壁注塑高速取出、注塑模內鑲件以及CNC金屬加工整體自動化解決方案等細分領域，具有獨創性的設計理念和核心技術，在行業處於領先地位。

“一切為了客戶”的全新理念，貫穿於威特爾品質控體系統全過程，威特爾團隊將以“為客戶創造價值”為已任，致力於踐行“中國製造2025”而努力！

S.Z.VICTOR Automation Technology Co.,Ltd. Is a high-tech enterprise of national,she was specializing in R&D industrial intelligent equipment and manufacturing, also system integration in applications, as well as the factory overall case solution of wisdom.

Victor have the core-technology team that is base on foreign advanced technology for 20 years, have the courage to the exploring and innovative, has acquired a number of core technologies in the field of intelligent equipment with independent intellectual property rights , independent R&D and manufacturing of industrial robots, has been widely used ing plastic injection molding ,CNC metal processing,metal stamping, automatic spraying, stacking handing ,metal welding and other fields, especially in high-speed thin walled injection taken out ,injection molding inserts and automation solutions on CNC metalworking whole case and other segments , we have the ingenious design and core technology made be the industry leader status.

“Everything for the customers”is our new concept, it was throughout the entire process in the quality control system of Victor, Victor’s mission will be “create value for customers”, and commit to practice”Chinese wisdom made 2025”.

 我们的愿景：让客户满意！

 我们的宗旨：为客户创造价值！

 我们的理念：制造精品，不做赝品！

 我们的使命：打造世界级的科技品牌！

 我们的核心价值观：天道酬勤，自强不息；锐意进取，务实创新！

描二维码，关注“威特尔机器人”微信公众号，获取更多最新动态资讯！
